FELDER

• For soldering copper pipes in cold and hot water installations according to DVGW working leaflet GW 2

• DIN EN 29453

• ø 2.7 mm

• For flux-free brazing of Copper pipes, especially in the Cold and air conditioning sector

• Silver-containing copper brazing alloys with phosphorus content for flux-free soldering of copper pipes in oil, gas and liquid gas installations as well as in Heating and drinking water installations with pipe dimensions over 28 x 1.5 mm.

• Rod size: 500 mm x 2 mm, square


- High-quality, halide-activated, lead-free solder wire for manual and automatic soldering in electrical engineering, electromechanics and electronics- High wetting speed and spread on all surfaces commonly used in electrical engineering- No flux splashes on the assembly, system components or the us ...

- Flux for soldering copper and copper alloys in copper pipe installation, radiator construction, plumbing work, dip soldering, fitting manufacture and other soldering work- Yellowish white pasty ...

• For brazed joints of Cu water pipes in drinking water and heating installations using corresponding flux

• 1 coil 100g fitting solder no. 3, 97% tin, 3% copper, DIN EN 29453

• 1 bottle 100g fitting solder paste, 60% metal content, 97% tin, 3% copper, DIN EN 29453, 40% liquid content, DIN EN 29454 3.1.1.C


• DIN EN 29453

• Triangular bars

• 400 mm long, roughly 250 g / bar


• For all soldering operations, excluding electronics

• Solder wire SP L-PbSn-40

• Working temperature: approx. 240°C


• For soldering steel, malleable cast iron and copper alloys, and for soldering copper pipes in the solar system sector

• L-Ag44, DIN 8513 flux-coated, DIN EN 1045, Model FH 10

• ø 2.0 mm


• Alloy L-CuP6 (DIN 8513)

• Working temperature: 730°C

• Tensile strength of joint: 250 (N/mm²)


• For soldering in electronics and electrical engineering

• Corrosion does not occur in non-ferrous metals, but the solder joint should be cleaned nevertheless

• DIN EN 29464 1.1.2C


• Silver braze and brazing flux for soldering steel, stainless steel, malleable cast iron, copper, cu alloy, nickel, nickel alloys and hard metal

• 4 silver solder rods with 40% silver content, DIN 8513

• 1 bottle at 30 g


• Consisting of:

• Soldering fluid (order no. 90 073 12)

• Soldering grease (order no. 90 073 15)


• For soldering titanium zinc gutters and pipes, and galvanised sheet steel with corresponding flux

• 3 rods of solder, 40% tin, 60% lead, DIN 1707

• 1 soldering fluid ”ZD“, DIN 8511, F-SW11


• For all soldering operations in electronics and electrical engineering

• Corrosion does not occur in non-ferrous metals, therefore the solder joints do not need to be cleaned

• Solder wire “RA“, Sn60Pb40


• For all soldering operations in electronics

• Corrosion does not occur in non-ferrous metals, therefore the solder joints do not need to be cleaned

• Solder wire “RA“, L-PbSn-40


• Brazing fluxes for soldering copper, brass and gunmetal

• In paste form

• Effective range: 500 - 800°C


• For soldering copper pipes in cold and hot water installations in accordance with DVGW worksheet GW 7

• DIN EN 29454 3.1.1.C

• The flux residues are cold-water-soluble


• DIN EN 29453

• Triangular bars

• 400 mm long, roughly 250 g / bar


• For removing solder joints in electronic components

• Place the desolder wick on the corresponding solder joint and press on with the hot iron

• The solder is absorbed by the copper strand


• For brazed joints of Cu water pipes in drinking water and heating installations using corresponding flux

• 1 coil 2.7 mm ø, 100 g fitting solder no. 3 97% tin, 3% copper, DIN EN 29453

• 1 tube 35 g fitting solder grease, DIN EN 29454.1


• For all soldering operations, excluding electronics and electrical engineering

• The flux residues are corrosive and should be removed thoroughly

• DIN EN 29454 1.3.1.1C


• Cleaning agent for soldering tips

• Dimensions: 65 x 45 x 20 mm

• For brazing for copper, brass and gunmetal

• No flux is required for copper-on-copper solders

• 4 rods of copper brazing solder no. 94, L-CuP6, 94% copper, 6% phosphorus, DIN 8513


• Aluminium brazing and brazing flux

• For soldering rolled and cast aluminium alloys

• 4 aluminium solder rods with 12% silicon content
