FELDER

24 / 29 FELDER

Multiple variants

Fittings solder "Cu-Rotin ® 3"

Immediately available

For soldering copper pipes in cold and hot water installations according to DVGW working leaflet GW 2
DIN EN 29453
ø 2.7 mm

90 073 31

Salmiak stone

Immediately available

Cleaning agent for soldering tips
Dimensions: 65 x 45 x 20 mm

90 039 75

Soft soldering flux CU Ropuls DIN EN 29454 tin of 70g

Immediately available

For soldering copper pipes in cold and hot water installations in accordance with DVGW worksheet GW 7
DIN EN 29454 3.1.1.C
The flux residues are cold-water-soluble

90 073 04

Cleaning fleece, metal free, approx 60 x 130mm bag of 10

Immediately available

Metal-free
Approx. 60 x 130 mm
PU = 10 units
Unit price only applies to orders of 10 units!

90 073 10

Silver solder set

Immediately available

Silver braze and brazing flux for soldering steel, stainless steel, malleable cast iron, copper, cu alloy, nickel, nickel alloys and hard metal
4 silver solder rods with 40% silver content, DIN 8513
1 bottle at 30 g

90 073 12

Solder water 50ml

Immediately available

For soldering iron, steel, brass, copper, lead and tinplate
Suitable for leaded glass soldering
Remove flux residues carefully

90 516 98

Silver solder pack DIN EN 1044, Ag 203 (L-Ag44) 5 x 2mm rods in a quiver

Immediately available

For soldering steel, malleable cast iron and copper alloys, and for soldering copper pipes in the solar system sector
L-Ag44, DIN 8513 flux-coated, DIN EN 1045, Model FH 10
ø 2.0 mm

90 073 06

Felder copper braze square rod, 500mm long 1kg

Immediately available

Alloy L-CuP6 (DIN 8513)
Working temperature: 730°C
Tensile strength of joint: 250 (N/mm²)

90 073 21

Electronic solder 100g

Immediately available

For all soldering operations in electronics and electrical engineering
Corrosion does not occur in non-ferrous metals, therefore the solder joints do not need to be cleaned
Solder wire “RA“, Sn60Pb40

90 073 24

Craft solder set

Immediately available

Consisting of:
Soldering fluid (order no. 90 073 12)
Soldering grease (order no. 90 073 15)

90 073 19

Craft solder 100g

Immediately available

For all soldering operations, excluding electronics
Solder wire SP L-PbSn-40
Working temperature: approx. 240°C

90 073 25

Special installation solder set

Immediately available

For brazed joints of Cu water pipes in drinking water and heating installations using corresponding flux
1 coil 100g fitting solder no. 3, 97% tin, 3% copper, DIN EN 29453
1 bottle 100g fitting solder paste, 60% metal content, 97% tin, 3% copper, DIN EN 29453, 40% liquid content, DIN EN 29454 3.1.1.C

90 073 18

Solder removal braid 1 x 1.6m roll

Immediately available

For removing solder joints in electronic components
Place the desolder wick on the corresponding solder joint and press on with the hot iron
The solder is absorbed by the copper strand

90 073 15

Solder grease 20g

Immediately available

For all soldering operations, excluding electronics and electrical engineering
The flux residues are corrosive and should be removed thoroughly
DIN EN 29454 1.3.1.1C

90 073 23

Roofers soldering set

Immediately available

For soldering titanium zinc gutters and pipes, and galvanised sheet steel with corresponding flux
3 rods of solder, 40% tin, 60% lead, DIN 1707
1 soldering fluid ”ZD“, DIN 8511, F-SW11

90 073 26

Installation solder set

Immediately available

For brazed joints of Cu water pipes in drinking water and heating installations using corresponding flux
1 coil 2.7 mm ø, 100 g fitting solder no. 3 97% tin, 3% copper, DIN EN 29453
1 tube 35 g fitting solder grease, DIN EN 29454.1

90 516 91

Tin solder rods DIN EN 29453 S-Pb65Sn35400mm rods 5kg supplied

Immediately available

DIN EN 29453
Triangular bars
400 mm long, roughly 250 g / bar

90 073 20

Radio solder 100g

Immediately available

For all soldering operations in electronics
Corrosion does not occur in non-ferrous metals, therefore the solder joints do not need to be cleaned
Solder wire “RA“, L-PbSn-40

90 073 05

Flux for silver solder No. 1 100g

Immediately available

Brazing fluxes for soldering copper, brass and gunmetal
In paste form
Effective range: 500 - 800°C

90 073 11

Electronic solder paste 1 x 20g can

Immediately available

For soldering in electronics and electrical engineering
Corrosion does not occur in non-ferrous metals, but the solder joint should be cleaned nevertheless
DIN EN 29464 1.1.2C

90 073 29

Copper brazing set

Immediately available

For brazing for copper, brass and gunmetal
No flux is required for copper-on-copper solders
4 rods of copper brazing solder no. 94, L-CuP6, 94% copper, 6% phosphorus, DIN 8513

90 073 02

Fitting solder paste DIN EN 29453 1 x 250g can

Immediately available
