• Rated current: 32 A

• Rated voltage: 450 V

• Continuous operating temperature: max. 105°C


• Rated current: 32 A

• Rated voltage: 450 V

• Max. continuous operating temperature: 105°C

• For cable cross-sections from 0.14-4.0 mm²

  Package consisting of:

• 600 Connection terminals 2-wire, type 221-412

• 450 Connection terminals, 3-wire, type 221-413


• External dimensions (W x H x D): 260 x 65 x 155 mm

• Weight: 2.1 kg
  Contents:
  COMPACT connection terminals:

• 2 x 0.14 - 4 mm² Ref.-Nr.: 221-412 (100 units)


• Rated current: 24 A

• Rated voltage: 450 V

• Continuous operating temperature: max. 105°C


• Rated current: 32 A

• Rated voltage: 400 V

• Rated impulse voltage: 4 kV


• External dimensions (W x H x D): 260 x 65 x 155 mm

• Weight: 2.1 kg
  Contents:
  COMPAKT push-wire connectors

• 2 x 0.5 - 2.5 mm² Ref. no.: 2273-202 (40 units)


• For cable cross-sections from 0.5-2.5 mm²

  Package consisting of:

• 600 push-wire connectors 2-wire, white 2273-202

• 900 push-wire connectors, 3-wire, orange 2273-203


- Protection class: IPX8- Unlimited shelf life- Closure type: Latching- Gel material: Polyurethane- Working temperature: 0 - 40- UV-resistant ...

• External dimensions (W x H x D): 442 x 117 x 357 mm

• Internal dimensions (W x H x D): 378 x 81 x 313 mm

• Weight: 2.1 kg
  Contents:
  COMPAKT push-wire connectors


• 0,25-2,5 (4 ?„f") mm²

• Expandable: 5-5.2 mm

• Contents: 10 strips for 10 signs per unit

• 0.5-16 (25 ,,f“) mm²

• For the main distribution board with separate FI/LINE PROTECTION switches for each circuit. Includes all components required for wiring a feed and connecting 14 Alternating current and 2 three-phase circuits. Connection of the L and N lines from the FI/LINE PROTECTION switch to the circuits via installation terminal blocks without disconnection option. Separation of the N potentials for the insulation resistance measurement via the FI/LINE PROTECTION switches.

• Scope of delivery:
  - 16 x installation terminal blocks NT/L/PE 2.5 (4) mm2
  - 2 x installation terminal blocks L/L2.5 (4) mm2
  - 1 x termination and intermediate plate
  - 3 x 2-wire distribution feed terminal, grey, 16 (25 "f") mm2
  - 1 x 2-wire distribution feed terminal, blue, 16 (25 "f") mm2
  - 1 x 2-wire distribution feed terminal, green-yellow, 16 (25 "f") mm2
  - 1 x end and intermediate plate
  - 2 x end terminal, 10 mm wide
  - 1 x labelling strip, white, 0.5 m
  - 1 x WMB labelling card 1 ... 50 (2 x)
  - 1 x WMB labelling card L1, L2, L3, N, PE, L1, L2, L3, N, PE (10 x)
  - 1 x comb jumper 1-3
  - 1 x fibre-tip pen, smudge-proof

• 0,25-2,5 (4 ?„f") mm²

• Contents:

• 2-conductor isolating and measuring terminal, with touch-proof test sockets for test plugs ø 4 mm, Ref.-No.: 2007-8821 (6 units)

• 2-way circuit bridge, insulated, Ref. No.: 2007-8442 (3 units)
  - 1-3-5 bridge, insulated, ref. no.: 282-435/011-000 (1 piece)


• Protection Type: IP20

• Ethernet 10/100 Mbit/s

• Field assembly without special tools


• 0.25 - 2.5 (4 “f”) mm²

• 0.8 mm

• For sub-distribution with an Earth-leakage circuit breaker. Includes all components required for wiring a feed and connecting 9 Distribution of the RCD potential via 1 N busbar 10 x 3 mm.

• Separation of the N potentials for insulation resistance measurement via isolating slides in the installation terminal blocks and 1 three-phase circuit.

• Scope of delivery:
  - 10 x installation terminal blocks NT/L/PE, 4 mm2
  - 1 x installation terminal blocks L/L, 4 mm2
  - 1 x termination and intermediate plate
  - 3 x 2-wire distribution feed terminal, grey, 16 mm2
  - 1 x 2-wire distribution feed terminal, blue, 16 mm2
  - 1 x 2-wire distribution feed terminal, green-yellow, 16 mm2
  - 1 x terminating and intermediate plate
  - 1 x 1-wire Ladders N disconnect terminal, blue, 16 mm2
  - 1 x end and intermediate plate
  - 1 x end terminal, 10 mm wide
  - 1 x busbar support with end clamp function
  - 1 x busbar, tin-plated 0.2 m
  - 1 x busbar cover, transparent 0.2 m
  - 1 x labelling strip, white 0.5 m
  - 1 x WMB labelling card 1 ... 50
  - 1 x WMB labelling card L1, L2 ... N, PE
  - 1 x Fibre pen, smudge-proof

• 11 mm wide

• Contactable shield diameter 3-8 mm

• Nominal input voltage: 100 V A/C-240 V

• Nominal output voltage: 24 V D/C

• 1-phase


• For the main distribution board with two Earth-leakage circuit breakers. Includes all components required for wiring a feed and connecting 9 Alternating current and 1 three-phase circuit.

• Manifolds the RCD potentials via 2 N busbars 10 x 3 mm. Separation of the N potentials for the insulation resistance measurement via isolating slides in the installation terminal blocks.

• Scope of delivery:
  - 16 x installation terminal blocks NT/L/PE, 4 mm2
  - 2 x installation terminal blocks L/L, 4 mm2
  - 2 x termination and intermediate plate
  - 3 x 2-wire distribution feed terminal, grey, 16 mm2
  - 1 x 2-wire distribution feed terminal, blue, 16 mm2
  - 1 x 2-wire distribution feed terminal, green-yellow, 16 mm2
  - 1 x termination and intermediate plate
  - 2 x 1-wire Ladders N disconnect terminal block, blue, 16 mm2
  - 1 x end and intermediate plate
  - 1 x end terminal, 10 mm wide
  - 2 x busbar supports with end clamp function
  - 1 x busbar, tin-plated 0.2 m
  - 1 x busbar cover, transparent 0.2 m
  - 1 x labelling strip, white 0.5 m
  - 1 x WMB labelling card 1 ... 50
  - 1 x WMB labelling card L1, L2 ... N, PE
  - 1 x Fibre pen, smudge-proof

• 0.5 - 6 (10 “f”) mm²
