Helios

24 / 91 Helios
Hauptbild
Multiple variants
Small room fan MiniVent M1 100 (V = to 90 m³/h)
Immediately available
  • Area of application
  • For bathroom, toilet, storeroom, cellar, etc.
  • Ventilation of internal rooms
Hauptbild
Multiple variants
Fan unit model ELS (V = up to 100 m³/h)
Immediately available
  • Area of application:
  • Bathroom, lavatory, domestic kitchens, stockrooms and storage rooms in private and public residential units, hotels or other buildings according to DIN 18017-3
  • Installation position: ceiling / wall
Hauptbild
Multiple variants
Flush-mounted Helios housing, model ELS-GU
Immediately available
  • For one and two-room ventilation
  • Connection: 80 mm
  • Suitable for blower unit ELS + ELS-EC
Hauptbild
Multiple variants
Fan units type ELS-NFC (V = up to 100 m³/h) for flush-mounted housing, parameterisable via app
Immediately available
  • EC technology, particularly economical in consumption
  • Facade with filter inserts
  • Voltage: 230V, 50 Hz
Hauptbild
Multiple variants
Pipe fan InlineVent® RR and RRK (V = up to 1260 m³/h)
Immediately available
  • Design: Radial
  • Extracted volume: 175-1260 m³/h
  • Acoustic pressure: 36 dB (A)
Hauptbild
98 006 11
Wall mounting set WES 90
Immediately available
  • For flush-mounting of M1 models
  • Adjustable from 260 to 500 mm
  • External closure via automatic damper or fixed baffle
Hauptbild
Multiple variants
Metal weather protection grill
Immediately available
  • Aluminium
  • For covering ventilation openings
  • With insect screen and screw fastening
Hauptbild
Multiple variants
Plastic disc valves KTV for exhaust air
Immediately available
  • Made of impact-resistant plastic
  • Quantity setting with rotating valve plate
  • For use in areas with no specific fire protection requirements
Hauptbild
Multiple variants
Hose clamp S 100
Immediately available
  • For secure connection of hoses
  • Metal band with turnbuckle
  • Nominal ø: 100 mm
Hauptbild
Multiple variants
MTVA for waste air mode
Immediately available
  • Made of metal
  • With clamping spring bracket for direct insertion in pipes or walls from 20 mm thickness
  • Installation in sheet metal duct walls and thin panels using installation ring EBR (accessories)
Hauptbild
Multiple variants
Pipe fan MultiVent® MV (V = up to 930 m³/h)
Immediately available
  • Design: semi-axial
  • Extracted volume: 190-910 m³/h
  • Acoustic pressure: 34/38 dB (A)
Hauptbild
98 018 31
Helios permanent filter ELF-ELS
Immediately available
  • Suitable for ELS fan inserts
  • Easy to clean in the dishwasher
  • PU = 2 units
Hauptbild
98 029 86
Device unit with internal panel type EcoVent Verso KWL EC 45-160
Immediately available
  • Extracted volume: 14/24/32/37/45 m³/h
  • Voltage: 12 V DC
  • Protection type: IP 20
Hauptbild
Multiple variants
Speed switch ESA/U 1
Immediately available
  • Continuous electronic rotational speed controller for continuous rotational speed control of AC fans
  • With 0 position
  • Uncontrolled switch output
Hauptbild
Multiple variants
Shutter with connecting muff
Immediately available
  • For covering and insertion into round ventilation openings
  • Made of break-resistant plastic
  • With insertion connector, automatic
Hauptbild
Multiple variants
Flat plastic duct check valve
Only a few items left in stock
  • DN 100 with wall connection
Hauptbild
Multiple variants
Flat radial fan sound-proofed, Silent Box SB, DN 125-250 (V = up to 1190 m³/h)
Immediately available
  • Extracted volume from 230 to 1190 m³/h
  • Energy-efficient radial fan with forward curved drum wheel
  • Virtually silent with higher volume and pressure output
Hauptbild
98 022 89
Helios SlimVent SVS 125 B Flat radial pipe fan 230 V 50 Hz, capacitor IP 44
Currently not in stock - Time of delivery: approx. 3-5 weeks
  • Flow rate from 245 to 840 mm
  • Flat radial fan with 2 fixed output levels or speed control by means of ESU 1 electronic actuator or 2 DS 2/2 level switches
  • With 50 mm thick fibreglass panel
Hauptbild
98 022 77
Helios surface-mounted housing ELS-GAP
Immediately available
  • Rear exhaust vent DN 80
  • Housing made of impact-resistant plastic
  • Colour: Alpine white
Hauptbild
Multiple variants
Hot water heating register WHR-R
Only a few items left in stock
  • Housing made of galvanised sheet steel
  • Connections on both sides with rubber lip seal for standard pipes
  • Air hear with aluminium disks, pressed on copper pipes
Hauptbild
Multiple variants
Ventilation housing flush-mounted model ELS-GUBA
Immediately available
  • Compatible with all ELS/ELS-EC Series Fan units
  • DN 80 exhaust vent
  • Exhaust vent can be rotated sideways, upwards, left or right
Hauptbild
Multiple variants
Helios (Small room fans) MiniVent M1/100 black
Immediately available
  • Area of application
  • For bathroom, toilet, storeroom, cellar, etc.
  • Ventilation of internal rooms
Hauptbild
Multiple variants
Cover flaps VK
Immediately available
  • Self-actuating overpressure flaps for external closure of flue gas openings
  • Made of break-resistant UV-resistant plastic
  • Colour white
Hauptbild
Multiple variants
Connecting muff
Immediately available
  • Nominal ø: 100 mm
  • With square flange plate for connecting pipes and hoses to flat surfaces
  • Made of plastic

Helios fans – quality and innovation for professional Ventilation solutions



Helios Ventilatoren stands for innovative ventilation solutions that are characterized by maximum efficiency, reliability and flexible application options. Whether for residential spaces, commercial buildings or industrial applications – Helios products meet all the requirements of modern ventilation technology. With well-thought-out designs, compact construction and advanced EC technology, Helios offers solutions that save energy while guaranteeing the highest performance.



Helios fans and fans

Versatile solutions for sewer systems

Helios Pipe Fans

Helios MultiVent® Duct Fans

MultiVent duct fans are the optimal choice for small to medium-sized rooms and tight installation situations.

  • Housing diameter is slightly larger than the ventilation pipe – ideal for confined spaces.
  • Flexible installation options: horizontal, vertical or overhead.
  • Models with AC or energy-efficient EC technology available.
  • Perfect for applications under suspended ceilings.



InlineVent RR – Centrifugal Tube Fans

InlineVent RR combines the simple installation of axial designs with the pressure strength of centrifugal fans.

  • Unlimited controllability for maximum flexibility.
  • Low sound power despite high performance.
  • Optionally with energy-saving EC technology.
  • Pressure range: Excellent performance at equipment resistors and long air paths.



SlimVent – Centrifugal Tube Fans in Slim Design

SlimVent is the space-saving solution for confined installation situations.

  • Extra-flat housing – barely higher than the tube diameter.
  • High pressure reserves: Ideal for longer pipe distances and greater resistances.
  • Energy-saving thanks to efficient radial impellers.
  • Models with silenced AcousticLine design available.
Helios MultiVent

Compact, quiet and energy-efficient

Helios Small Room Fan

The small room fans from Helios offer reliable ventilation for bathrooms, toilets, kitchens or small commercial spaces. Thanks to their modern design and whisper-quiet operation, they set standards in comfort and efficiency.



MiniVent M1 – The premium solution for small spaces

  • Two power levels for individual requirements.
  • IP 45 – suitable for damp rooms such as bathrooms and guest toilets.
  • Noise level: Particularly quiet in operation, ideal for living areas.



HV 100 and HV 150 small room fans – flexibility for all rooms

The HV 100 and HV 150 models are versatile and easy to install.

  • Various installation options: wall or ceiling.
  • Low-noise ball bearings with long-term lubrication
Helios MiniVent M1

Innovative systems for a healthy indoor climate

Helios Residential Ventilation

Helios' residential ventilation systems combine comfort with energy efficiency and ensure needs-based ventilation in residential and commercial buildings.



ELS single-tube ventilation systems – Quiet and efficient

Specially developed for interior bathrooms and toilets in accordance with DIN 18017-3.

  • Extremely quiet thanks to ultraSilence® technology.
  • Economical in energy consumption thanks to modern EC technology.



MiniVent M1 – Compact residential ventilation

  • Elegant design for discreet integration into living spaces.
  • High energy efficiency thanks to integrated EC technology.
  • Durable and low-maintenance
Blower unit ELS EC 60 N
