- Single collar:
- Size 58 x 58 mm, height 13 mm
Double collar: - Size 56 x 108 mm, height 13 mm
- U-shaped pipe bend unit
- Scope of delivery:
- 2 Flipflex louvre bends
- Mounting rail and 2 protective tubes
- Single collar:
- Size 58 x 58 mm, height 13 mm
Double collar: - Size 56 x 108 mm, height 13 mm
- Black-grey
- Length: 160 mm
- L-shaped pipe bend unit
- Scope of delivery:
- 2 Flipflex louvre bends
- Mounting rail and 2 protective tubes
- Single collar:
- ø 58 mm
- Height 13 mm
Double collar:
- Traffic white, similar to RAL 9016
- With extra-large dimensions to conceal a lot
- Smooth surface
- Dark grey, similar to RAL 7021
- With extra-large external ø to conceal a lot
- Smooth surface
- U-shaped pipe bend unit
- Scope of delivery:
- EPP insulation box
- Mounting rail and 2 protective tubes
Radiator connection
For quick, clean and planned connection from the wall.
Put the wall box into the recess and fix at the appropriate height. The wall box is designed in such a way that various installation heights can be easily achieved. In doing so, the wall rail provides a secure fit. Afterwards, the wall can be fully plastered. The protective pipes also protect the pipe from plasterer damage.
After the wall is plastered, the connection cables are laid over the floor and connected to the wall box. After the pressure sample (just via the connection between flow and return), the screed can be incorporated. Afterwards, you can lay the flooring. Due to this order of work steps, the pipes laid in the ground cannot be damaged by the plasterer’s devices.
Delivery and assembly of the radiators is no longer required before plastering the wall. Preliminary financing and multiple mounting with potential radiator storage is not required. Thr risk of damage and theft is minimised. Plasterer and painter reworking is not required.
- For radiator connection incl. red plastic fastening clip
- Suitable for drywall rail
- Centre distance: 50 mm, for 15 to 17 mm pipes
- Shiny surface
- With extra-large external ø to conceal a lot
- Smooth surface
- Single collar:
- Size 58 x 58 mm, height 13 mm
Double collar: - Size 56 x 108 mm, height 13 mm
- Traffic white, similar to RAL 9016
- With extra-large external ø to conceal a lot
- Smooth surface
- Traffic white
- Length: 160 mm
- Flexible pipe guide elbow, for connecting flexible pipelines to heating manifolds.
- Radius: 60 mm
- Ø internal: 17.7 mm
- Measuring:
Dimension from the unfinished floor to the lower edge
Measure tap block. Mark the
pipe in accordance with the table included..
Pushing over:
Push the flipflex over the pipe up to the marked
point.
Bending:
Bend the flipflex including the pipe with a flick of the
wrist. This is particularly easy if you
encompass both ends of the flipflex as you do so!
Connecting:
Push the screw connection onto the
calibrated pipe and tighten on the tap block.
Fixing:
Connect the two pipelines on the flipflex
with the fixing bracket.
Nail it to the floor.
Securing:
To ensure the accurate centre distance,
put the double clip on the top. - Radius: 100 mm
- Internal ø: 20.8 mm
- Shiny surface
- With extra-large dimensions to conceal a lot
- Smooth surface
- Radius: 60 mm
- ø inside: 14.6 mm
- For Pipe ø: 10/14 mm
- Shiny surface
- Length: 160 mm
- Oak
Single collar: - Size 58 x 58 mm, height 13 mm
Double collar: - Size 56 x 108 mm, height 13 mm
- For radiator connection from the floor
- Single collar:
- Size 58 x 58 mm, height 13 mm
Double collar: - Size 56 x 108 mm, height 13 mm
- Dark grey, similar to RAL 7021
- With extra-small external diameter so that two individual collars can be fitted next to one another (with 50 mm spacing)
- Surface: matt silk
- Radius: 75 mm
- Internal ø: 18.6 mm
- For pipe ø: 17/18 mm
