MEPA®

• For wall sealing of steel, acrylic, mineral cast and ceramic shower trays and Bathtubs

• Scope of delivery:
  - 1 roll of Aquaproof bathtub sealing tape

• Anti-rotation and soundproofing system (ADS)

• Height-adjustable from 65-190 mm

• Adjustable from 700 x 700 mm to 1200 x 1200 mm


• Anti-rotation and soundproofing system (ADS)

• Height-adjustable from 55-190 mm

• 13 or 15 height-adjustable screw feet


• 5 height adjustable screw feet

• For super-flat steel and acrylic shower trays adjustable from 700 x 700 mm to 1000 x 1000 mm

• ADS (Anti-rotation and soundproofing system)


• Anti-rotation and soundproofing system (ADS)

• Height-adjustable from 65-190 mm

• Adjustable from 700 x 700 mm to 1000 x 1800 mm


• 5 height adjustable screw feet

• For steel and acrylic shower trays adjustable from 700 x 700 mm to 1000 x 1000 mm

• ADS (Anti-rotation and soundproofing system)


• 2 cross members 550 x 85 x 25 mm

• 4 height-adjustable screw feet

• Laterally adjustable up to 130 mm


• To supplement an Aquaproof 3D flush-to-floor tray sealing tape, for flush-fitting trays and walls

• Scope of delivery:
  - 3 x Aquaproof 3D corner
  - Connecting pieces
  - Separating strip 2.60 m

• For fixing and support of steel or acrylic bathtubs

• 3 sound-insulated bath strips for bathtubs und 2 sound-insulated bath strips for shower trays

• Bath strips, each 700 mm long


• 2 cross members 550 x 85 x 25 mm

• 4 height-adjustable screw feet

• Laterally adjustable up to 130 mm


• For sizes up to 1800 x 800 mm with material thickness from 2.3 mm

• 2 angle beams

• 4 height-adjustable screw feet


• 5 height adjustable screw feet

• For steel and acrylic shower trays adjustable from 700 x 700 mm to 900 x 900 mm

• Height-adjustable from 125 to 180 mm
  Note:
  For sizes of 900 x 900 mm and above, assembly only in conjunction with MEPA tray anchor (93 969 23) or MEPA tray slat (93 969 22)!

• For wall sealing of steel, acrylic, mineral cast and ceramic shower trays and Bathtubs

• Scope of delivery:
  - 1 roll of Aquaproof bathtub sealing tape
  - 1 roll of sound insulation strips
  - 1 roll of tile separating strips


• Anti-rotation and soundproofing system (ADS)

• Height-adjustable from 95-185 mm

• Adjustable from 700 x 700 mm to 1500 x 1800 mm


• For sizes up to 1800 x 800 mm

• Height adjustable from 120 to 190 mm

• 2 cross members 550 x 85 x 25 mm


• For sizes up to 1800 x 800 mm

• Convenient adjustment of screw feet throughout assembly

• Screw feet with wide adjustment range from 130 mm to 195 mm


• For sizes up to 1800 x 800 mm with material thickness from 2.3 mm

• 2 angle beams

• 4 height-adjustable screw feet


• Start/stop and 2-volume 6-7.5 l

• Top/front operation

• From 01/2004 to 12/2009

• Start/stop 6-9 l

• Front operation

• To 12/1999

• Start/stop and 2-volume 6-7.5 l

• From 04/2006 to 12/2013

• For fixing and support of steel or acrylic bathtubs

• 3 tray anchors in the kit, of which 2 have clamping brackets

• Soundproofed support surface


• For perfect wall sealing of showers and baths made of steel, acrylic and cast mineral composite
  Delivery contents:

• 1 roll of bath sealing tape Aquaproof

• Sound-proofing strips


• Start/stop 6 l

  Filling valve set:

• B11/B13 (to 12/1999)
  Consisting of:

• Filling valve


- For additional support of shower trays made of steel, acrylic, mineral casting.- Height adjustable from 55 mm to 190 mm- Diameter 80 mm- ADS (Anti-Twist & Soundproofing System) ...
