strawa
Multiple variants
Stainless steel heating manifold strawa e-class 63..
Immediately available
- Stainless steel flow and return bar (VA)
- Primary side: 2 freely rotatable nuts with DN 25 (1") IG, flat sealing
- Secondary side: DN 20 (3/4") ET with Euro cone, suitable for clamping screw connections
93 244 55
Water station W2-T130 type A, for 110 mm water meter DN20 (3/4")
Immediately available
- Water meter installation sections with 110 mm spacer tube- Pre-assembled ready for connection in flush-mounted cabinet- Ball valve (DVGW) DN 20 (3/4") with detachable screw connection- DN 20 (3/4") threaded connection on the outlet side- Dimensions (W x H x D): 220 x 220 x 130 mm- Colour of cover: ...
90 044 98
Control drive electrothermal Strawa type EGO-M30 230V M30x1.5
Immediately available
- The actuator for perfect hydraulic balancing
- For heating and cooling
- For underfloor heating distributors with connection thread M30 x 1.5
90 055 44
Control group VA 130/6 UPM3 for Underfloor heating
Immediately available
- Fixed value control for approx. 120 m² underfloor heating
- Suitable for all strawa e-class manifolds
- Grundfos UPM3 AUTO L 15-50 pump
Technical data:
Multiple variants
Water station W2
Immediately available
- Cover plate white coated RAL 9016
- Installation depth: 90 mm
- 2 universal water meters with distance pipe 80 mm, DN 20 (3/4”) external thread
Multiple variants
Water station, W2-D, insulated
Immediately available
- Cover plate coated white RAL 9016
- Installation depth: 90 mm
- With EPP insulation of the water sections
93 167 04
Water station W2-Lim-D size 3/4", with insulation
Immediately available
- Cover plate white, Limodor (LIM) plastic
- Installation depth: 90 mm
- With EPP insulation of the water sections
93 181 86
Water station, W2-D Type A without insulation DN20 (3/4")
Immediately available
- Cover plate coated white RAL 9016
- With inlet-side ball valve/outlet-side screw connection
- Installation depth: 90 mm
93 025 21
Water station W2-FR 3/4"
Immediately available
- Cover plate with stainless steel tile frame
- Installation depth: 110 mm
- 2 universal water meters with distance pipe 80 mm, DN 20 (3/4”) external thread
Multiple variants
Strawa connection station, model AS 12+13 h
Immediately available
- Fully pre-assembled in flush-mounted cabinet
- Installation depth: 90 mm - 120 mm
- Galvanised- front panel white RAL 9010
Return:
1x DN 20 (3/4“) flush pipe 110 mm, 2x DN 20 (3/4“) ball valves (with vertical secondary connection 1x DN 12 (3/8“) air plug)
Flow:
1x DN 20 (3/4“) ball valve, 1x t-piece for
DN 12 (3/8“) thermowell (for vertical secondary connection 1x DN 12 (3/8“) air plug)
93 244 54
Water station W1-T130 type A, for 110 mm water meter DN20 (3/4")
Immediately available
- Water meter installation sections with 110 mm spacer tube- Pre-assembled ready for connection in flush-mounted cabinet- Ball valve (DVGW) DN 20 (3/4") with detachable screw connection- DN 20 (3/4") threaded connection on the outlet side- Dimensions (W x H x D): 220 x 220 x 130 mm- Colour of cover: ...
93 024 32
Cover plate, white coated suitable for water station W2 (93 025 20)
Immediately available
- Cover plate coated RAL 9016
Multiple variants
Brine manifold e-class, model 37 VA, stainless steel (1.4301), DN50 (2“)
Immediately available
- Fittings: Brass press, nickel-plated
- Operating pressure: max 10 bar
- Operating temperature: max. +90 °C
90 606 43
Valve insert for Stainless steel manifold VA and e-class
Immediately available
- Suitable for e-class (series 1999 onwards)
- DN 15 (1/2")
- Actuator connection: M30 x 1.5
93 181 85
Water station, W2-D Type A with insulation DN20 (3/4")
Immediately available
- Cover plate coated white RAL 9016
- With inlet-side ball valve/outlet-side screw connection
- Installation depth: 90 mm
93 024 31
Cover plate with stainless steel tile frame suitable for water station W2-FR
Immediately available
- Stainless steel tile frame
93 025 22
Water station W2-LIM 3/4"
Immediately available
- Cover plate white, plastic
- Manufacturer Limodor (LIM)
- Installation depth: 90 mm
Multiple variants
Stainless steel heating manifold strawa e-class 53..
Immediately available
- Stainless steel flow and return bar (VA)
- Primary side: 2 freely rotatable nuts with DN 25 (1") IG, flat sealing
- Secondary side: DN 20 (3/4") ET with Euro cone, suitable for clamping screw connections
90 007 36
Transfer station Strawa AS11h, white,wall cabinet, size 330x370mm
Immediately available
- Pre-assembled
- Cabinet dimensions (W x H): 330 x 370 mm
- Installation depth: 90 - 120 mm
Multiple variants
Connection station Strawa, model AS 12+13 h Wh2
Immediately available
- Fully pre-assembled in flush-mounted cabinet
- Installation depth: 90 mm - 120 mm
- Galvanised- front panel white RAL 9010
Return:
1x DN 20 (3/4“) flush pipe 110 mm, 2x DN 20 (3/4“) ball valves (with vertical secondary connection 1x DN 12 (3/8“) air plug)
Flow:
1x DN 20 (3/4“) ball valve, 1x t-piece for
DN 12 (3/8“) thermowell (for vertical secondary connection 1x DN 12 (3/8“) air plug)
90 889 24
Strawa flow indicator set 1-4l/min. for return flow installation
Immediately available
- Suitable for e-class (Taconova)
- Construction year approx. 1999-2003
- Adjustment range 1-4 l/min
Multiple variants
Stainless steel heating manifold strawa e-class 52..
Immediately available
- Stainless steel flow and return bar (VA)
- Primary side: 2 freely rotatable nuts with DN 25 (1") IG, flat sealing
- Secondary side: DN 20 (3/4") ET with Euro cone, suitable for clamping screw connections
Multiple variants
Water station
Immediately available
- Cover plate white coated RAL 9016
- Installation depth: 90 mm
- 2 universal water meters with distance pipe 80 mm, DN 20 (3/4”) external thread
Multiple variants
Top meter for strawa heating manifold e-class
Immediately available
- Suitable for e-class (series 2003-2006), 0-5 l/min
- DN 15 (1/2")
