SUNTEC®

• Universal service pump with pressure relief valve

• As a replacement for oil burner pumps with the same output / connections with and without LE function

• This includes the majority of SUNTEC models AS 47, ASV 47, AL 35, ALV 35, ALE 35 and ALEV 35


• Can be plugged in

• Suitable for AS/AL/AP/AU/AT/ALE pumps

• 220 V 50/60 Hz


• Suitable for Buderus: BE/BE-A 1.0-2.3 17-34 kW with LE function

• Model ALE 35C 9329

• 2-surface shaft


• Universal service pump with pressure relief valve

• As a replacement for oil burner pumps with the same output / connections with and without LE function

• This includes the majority of SUNTEC models AS 47, ASV 47, AL 35, ALV 35, ALE 35 and ALEV 35


• Shaft: two-surface

• Nozzle output right and left: DN 6 (1/8”)

• Suction/return flow pipe: DN 8 (1/4”)


• Suitable for Suntec: Series ALE all years of construction and AUV 47 with pressure relief valve from year 19 onwards

• Ref. no.: 991600

• Scope of delivery:
  - Mounting accessories

• Suitable for Suntec AS/AN/AE/AL/AT/AU/ALE oil pumps

• Scope of delivery:
  - 1 x filter set
  - 2 x Cover gaskets for new and old housing
  - 1 x O-ring for Pressure and vacuum test plug

• Ref. no.: 991533

• Scope of delivery:
  - 1 x AUV 47 L pump
  - 1 x ATUV 45 L pump
  - 2 x Filter inserts
  - 1 x Solenoid valves coil
  - 4 x Seal sets
  - 1 x spacer ring
  - 2 x plug cable
  - 1 x AU/AE conversion kit
  - 12 x connection nipple
  - 4 x Red. piece DN 8 x DN 6
  - 1 x case

• Rev.2 for AL/AU Series

• Scope of delivery:
  - Mounting accessories

• Scope of delivery:
  - 1 x AUV 47 L pump
  - 1 x AUV 47 R pump
  - 2 x Filter inserts
  - 1 x Solenoid valves coil
  - 4 x Seal sets
  - 1 x spacer ring
  - 2 x plug cable
  - 1 x AU/AE conversion kit
  - 12 x connection nipple
  - 4 x Red. piece DN 8 x DN 6
  - 1 x case

• Suitable for AS series

• Complete

• Can be plugged in

• For AS/AN/AE/AL/AT/AU/ALE

• Angular pump housing (from approx. constr. yt. 2001)

- Also suitable for Weishaupt: WL 5, 10, 20, 30- Type: ALV 35 C 9640- Shaft: 1-surface- Direction of rotation: Left- Nozzle connection: Left- Shaft Ø: 8 mm- Hub Ø: 32 mm- Inlet/return: DN 6 (1/8")- Ref. no.: 601 193 replaces 601 213 ...

• Suitable for Viessmann: Vitoflame 300 and Rotrex

• Ref. no.: 7822037

• For AS/AN/AE/AL/AT

• For round pump housing

• Suitable for AN/AE: Series 77/97, AP2/AT2/AL/ALE/A2L/AR: Series 75/95

• Delivery contents:
  - 1 x filter set, depth: 23 mm
  - 2 x cover gasket for new and old housing
  - 1 x O-ring for pressure and vacuum test plug

• Ref. no.: 991510


• ALEV 55C 9318

• Suitable for Buderus/Sieger: BE/BE-A 1.0-2.3 with LE function

• Shaft 2-surface


• for AS/AN/AE/AL/ALE/AT/AP

• Suitable for Suntec: Series AS, AP2/3 and first stage for Series AT2/3

• Ref. no.: 991430

• Scope of delivery:
  - Mounting accessories

• For J 3 - J 7

• Suitable for Suntec: Series ATUV/ATE2

• Scope of delivery:
  2 x valve core
  Seal sets and mounting accessories

• Ref. no.: 991559

• Suitable for SUNTEC®: AT2/3 Rev.2/4/6

• Ref. no.: 991503

• Scope of delivery:
  - 2 valve cores
  - Mounting accessories

• For J 3 - J 7
